Jasic MIG 500 Pulse Water Cooled MIG Welder

This machine is the flagship MIG welder from Jasic. The Jasic MIG 500 Pulse packs a huge punch on mild steel, stainless steel & aluminium. Spatter covered welds are a thing of the past when using this machine; the result the Jasic MIG 500 Pulse produces is smooth, consistent and spatter free. It is perfect for any fabrication shop as a result of its multi process capabilities, this means it is capable of pulse MIG, MIG/MAG, DC Lift TIG & MMA (stick welding). It is a true workhorse welding machine, an all in one “do it all” system. Outstanding features include a job storage system for repeatable and re-producable welds, synergic parameter setting & smart fan and water control.

There isn’t much you can throw at this machine that is cannot handle. Welds on 20MM+ thick steel & stainless steel are an easy task to accomplish with the Jasic MIG 500 pulse. It will put down a truly consistent and smooth welds that would impress even the best welders.

Finally, its huge 50% duty cycle at 500 amps allows the machine to weld 10MM – 12MM steel all day without ever stopping, or 25MM+ steel for a consistent 5 minutes out of a 10 minute period.

The warranty on the Jasic MIG 500 Pulse is 5 years one registered with Wilkinson Star UK.

Jasic MIG 500 Pulse Key Features

• Synergic and standard parameter setting
• Job storage system
• Self diagnostic of issues
• Synergic curves for all common materials and wire diameters
• Built in trolley that can accomodate full size gas bottles
• Suitable for 0.8MM – 1.6MM diameter welding wire including flux cored wires
• 4 roll wire feed unit for consistent and smooth feeding which is especially useful when welding aluminium
• Pulse MIG for consistent, smooth & spatter free welds

Technical Specifications

• Input voltage – 400V 3 phase
• Input current – 32A
• Amperage range – 30A – 500A
• No load voltage – 86B
• Duty cycle – 500A @ 50%
• Max wire spool size – 15KG
• Efficiency – 92%
• Protection/insulation class – IP23S/F
• Dimensions – 1080MM x 510MM x 1180MM
• Weight – 129KG

You can find a link to Jasic UK’s information page for this machine here.

The stand JM-500P package includes a 3M Starparts MB501 water cooled MIG torch, G-tech gas regulator, earth lead with clamp, gas hose with connections, trolley, water cooler & 5M interconnecting cable.
